Motherboard Manual
28
Italian
Specificazioni
Supporto
processore
AMD "Kabini" Athlon/Sempron APUs, AM1 Socket
* Si prega di consultare www.biostar.com.tw per la lista di supporto del
processore
Memoria
Supporta DDR3 1333/ 1600 Singolo Canale
2 x DDR3 DIMM Slot di Memoria Supporta fino a 16 GB Memoria
Ogni DIMM supporta non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 moduli
* Si prega di consultare www.biostar.com.tw per la lista di supporto del memoria.
Memorizzazione
Connettore 2x SATA 6Gb/s
Supporta nativo IDE & AHCI modo
Catena
AM1MH / AM1MD: Realtek RTL 8111G
10/ 100/ 1000 Mb auto negoziazione, capacita di duplex Meta / Completo
AM1ML: Realtek RTL 8106E
10/ 100 Mb auto negoziazione, capacita di duplex Meta / Completo
Codec Audio
ALC662
Canali Audio di Alta Definizione 5.1
USB
Slot 2x USB 3.0 (2 nei ingressi/ uscite posteriore)
Slot 6x USB 2.0 (2 nei ingressi/ uscite posteriore e 4 da distributori interni)
Slot di
espansione
Slot 1x PCIe 2.0 x16 (x4)
Slot 1x PCIe 2.0 x1
Ingressi/ Uscite
Posteriore
Mouse 1x PS/2
Tastiera 1x PS/2
Slot 1x HDMI (AM1MH)
Slot 1xDVI-D (AM1MD)
Slot 1x VGA
Slot 1x LAN
Slot 2x USB 2.0
Slot 2x USB 3.0
Jack audio 3x
Ingressi/ Uscite
Interni
Connettore 2x SATA 6.0Gb/s
Distributore 2x USB 2.0(ogni distributore supporta 2 slot USB 2.0)
Connettore con 4 pin x1
Connettore con 24 pin x1
Connettore Ventilatore processore x1
Connettore Ventilatore Sistema x1
Distributore Pannello Frontale x1
Distributore Audio Frontale x1
Distributore CMOS Diretto x1
Distributore Slot Stampante x1
Fattore di Forma Fattore di Forma Micro-ATX, 191 mm x 170 mm
Supporto SO
Windows XP / 7 / 8 / 8.1
Biostar si riserva il diritto di aggiungere o ritirare il supporto per qualsiasi SO
con o senza preavviso.
