![Biostar AM1ML Версия 7.x [32/35] Polish](/views2/1711108/page32/bg20.png)
Motherboard Manual
30
Polish
Specyfikacje techniczne
Obsługa procesora
AMD "Kabini" Athlon/Sempron APUs, AM1 Socket
* Proszę sprawdzić listę obsługiwanych procesorów na stronie internetowej
www.biostar.com.tw
Pamięć
Pojedynczy pamięci DDR3 1333/ 1600 Dwukanałowa
2 x DDR3 DIMM Pamięć Gniazda procesora (Slot), Maksymalna wielkość pamięci 16 GB
Każdy DIMM obsługuje jeden moduł non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3
* Proszę sprawdzić listę obsługiwanych pamięć na stronie internetowej
www.biostar.com.tw
Przechowywanie Złącze 2x SATA 6Gb/s, Obsługa rodzimy IDE & AHCI tryb
LAN
AM1MH / AM1MD: Układ RTL 8111G
10/ 100/ 1000 Mb auto negocjacja, pojemność dupleks Połowe / Pełny
AM1ML: Układ RTL 8106E
10/ 100 Mb auto negocjacja, pojemność dupleks Połowe / Pełny
Codec Audio
ALC662
Kanały Audio wysokiej Definicji 5.1
USB
2 x złącza USB 3.0 (2 przez tylne porty wejścia/ wyjścia oraz)
6 x złącza USB 2.0 (2 przez tylne porty wejścia/ wyjścia oraz 4 przez wewnętrzne porty)
Złącza rozszerzeń
złącza 1x PCIe 2.0 x16 (x4 Slot)
złącza 1x PCIe 2.0 x1
Tylne porty wejścia/
wyjścia
Myszka 1x PS/2
Klawiatura 1x PS/2
Port 1x HDMI (gniazdo) (AM1MH)
Port 1x DVI-D (AM1MD)
Port 1x VGA
Port 1x LAN
Porty 2x USB 2.0
Porty 2x USB 3.0
Porty audio 3x
Wewnętrzne porty
wejścia/ wyjścia
Złącza 2x SATA 6.0Gb/s
Złącza 2x USB 2.0 (każde złącze obsługuje dodatkowe 2 porty USB 2.0)
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x 1
Złącze przedniego panelu x1
Złącze audio przedniego panelu x1
Złącze bezpośrednie CMOS x1
Złącze port drukarki x1
Port szeregowy x1
Obudowa Obudowa Micro-ATX, 191 mm x 170 mm
Obsługa OS
Windows XP / 7 / 8 / 8.1
Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z
wypowiedzeniem lub bez wypowiedzenia.
