AM1MHP / AM1MDP / AM1MLP
33
Spanish
Especificaciones
Compatibilidad
con el procesador
AMD "Kabini" Athlon/Sempron APUs, AM1 Socket
*Por favor consultar con
www.biostar.com.tw para la lista de compatibilidad con el
procesador.
Memoria
Soporta DDR3 1333/ 1600 monocanal
2x DDR3 DIMM Ranura de memoria Soporta hasta 16 GB Memoria
Cada DIMM soporta un modulo non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3
*Por favor consultar con
www.biostar.com.tw para la lista de compatibilidad con el
memoria.
Almacenamiento
de información
Conector 2x SATA 6Gb/s, Soporta nativo IDE & AHCI modo
LAN
AM1MHP / AM1MDP: Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
AM1MLP: Realtek RTL 8106E
10/ 100 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio ALC662, Canales Audio de Alta Definición 5.1
USB
Ranura 2x USB 3.0 (2 en las entrada/salidas posteriores)
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores
internos)
Ranuras de
Extinción
Ranura 1x PCIe 2.0 x16 (x4)
Ranura 1x PCIe 2.0 x1
Ranura 1x PCI
Panel trasero de
E/S
Ratón 1x PS/2
Teclado 1x PS/2
Ranura 1x HDMI (AM1MHP)
Ranura 1x DVI-D (AM1MDP)
Ranura 1x VGA
Ranura 1x LAN
Ranura 2x USB 2.0
Ranura 2x USB 3.0
Socket audio 3x
Conectores en
placa
Conector 2x SATA 6Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Conector con 4 patillas x1
Conector con 24 patillas x1
Conector Ventilador procesador x1
Conector Ventilador Sistema x1
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Distribuidor Ranura Impresora x1
Distribuidor Ranura Serie x1
Factor de Forma Factor de Forma Micro-ATX, 226 mm x 170 mm
Soporte OS
Windows XP / 7 / 8 / 8.1
Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin
notificación.
2014/01/04
