Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
AMD "Kabini" Athlon/Sempron APUs, AM1 Socket
* Please refer to www.biostar.com.tw for CPU support list.
Memory
Supports Single Channel DDR3 1333/ 1600 (*DDR3 1600 depends on CPU)
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to www.biostar.com.tw
for Memory support list.
Storage 2x SATA 6Gb/s Connector, Supports Native IDE, AHCI Mode
LAN
AM1MHP / AM1MDP:
Realtek RTL 8111G, 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex
capability
AM1MLP:
Realtek RTL 8106E, 10/ 100 Mb/s auto negotiation, Half / Full duplex
capability
Audio Codec ALC662, 5.1 Channels, High Definition Audio
USB
2x USB 3.0 port (2 on rear I/Os)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 2.0 x16 Slot (x4)
1x PCIe 2.0 x1 Slot
1x PCI Slot
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x HDMI Port (AM1MHP)
1x DVI-D (AM1MDP)
1x VGA Port
1x LAN port
2x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
Internal I/Os
2x SATA 6.0Gb/s Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Printer Port Header
1x Serial Port Header
Form Factor Micro-ATX Form Factor, 226 mm x 170 mm
OS Support
Windows XP / 7 / 8 / 8.1
Biostar reserves the right to add or remove support for any OS with or without
notice.
