A870U3/A870
39
A870U3 A870
Conector SATA x6 Conector SATA x6
Conector do painel frontal x1 Conector do painel frontal x1
Conector de áudio frontal x1 Conector de áudio frontal x1
Conector de saída S/PDIF x1 Conector de saída S/PDIF x1
Conector da ventoinha da CPU x1 Conector da ventoinha da CPU x1
Conector da ventoinha do sistema x1 Conector da ventoinha do sistema x1
Conector para limpeza do CMOS x1 Conector para limpeza do CMOS x1
Conector USB 2.0 x2 Conector USB 2.0 x2
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Conector de alimentação x1
(4 p inos)
Conectores
na placa
Conector da para impressora x1 Conector da para impressora x1
Entradas/S
aídas no
painel
traseiro
Tec lad o PS /2 x 1
Rato PS/2 x1
Porta série x1
Porta LAN x1
Porta USB 2.0 (por SB850) x2
Porta USB 3.0 (por ASM1042) x2
Tomada de áudio x3
Tec lad o PS /2 x 1
Rato PS/2 x1
Porta série x1
Porta LAN x1
Porta USB 2.0 x4
Tomada de áudio x3
Tamanho
da placa
205 mm (L) X 305 mm (A) 205 mm (L) X 305 mm (A)
Característi
cas
especiais
Suporta as funções RAID 0 / 1 / 10 / 5 Suporta as funções RAID 0 / 1 / 10 / 5
Sistemas
operativos
suportados
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema
operativo com ou sem aviso prévio.
