Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
JUSBV1
ATXPWR2
COM 1
R J45U S B1
AUDIO1
USB3_0
USB2_0
(A870U 3)
(A870)
ATXPWR1
LAN
Codec
PEX1_1
PEX16_1
PEX1_2
PEX16_2
PCI2
PCI1
F_AUDIO1
J_ P R I N T 1
JSPDI FOUT1
JUSBV2
F_USB1F_USB2
SYS_FAN1
Super I/O
PANEL1
SATA2
SATA1
SATA5
SATA3
SATA4
SATA6
BIOS
BAT
JCMOS1
AMD
SB850
AMD
870
CPU_FAN1
Socket AM 3
DDR3_A1
DDR3_A2
DDR3_B2
DDR3_B1
Note: represents the 1■
st
pin.
