TA870U3+/TA870B BIOS Manual
22
PCI Express Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Configuration
> Port #04 Features
> Port #09 Features
> Port #10 Features
> NB-SB Port Features
> Port #02 Features
Port #02/04/09/10 Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Gen2 High Speed Mode [Disabled]
Link ASPM [Disabled]
Link Width [Auto]
Auto - RC only
advertize Gen2
capability.
Gen2 High Speed Mode
Options: Disabled (Default) / Auto
Link ASPM
Options: Disabled (Default) / L0s / L1 / L0x & L1
Link Width (Only for Port #02)
Options: Auto (Default) / x1 / x2 / x4 / x8 / x16
