TA870U3+/TA870B BIOS Manual
30
Manual Overclock System (M.O.S.)
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Notice:
OverClock Navigator [Manual OverClock]
Please Clear CMOS if system no display
after overclocking.
CPU/HT Reference Clock (MHZ) [200]
CPU Configuration [Auto]
Spread Spectrum [Disabled]
> Over-Voltage Configuration
> CPU FID/VID Control
> Hyper Transport Configuration
> DRAM Timing Configuration
> G.P.U Phase Control
Integrated Memory Test [Disabled]
BIO-unlocKING [Disabled]
Auto OverClock System [V6-Tech Engine]
Exit
Options
Disabled
Enabled
MOS is designed for experienced overclock users.
It allows users to customize personal overclock setting.
CPU/HT Reference Clock (MHz)
This item allows BIOS to select CPU Over Clock.
Options: 200 (Default) / 200~600
CPU Configuration
This item allows you to save CPU configuration.
Options: Auto (Default) / Configure 1~7
Spread Spectrum
This item allows you to control Spread Spectrum function.
Options: Disabled (Default) / Enabled
