A880G+/A785G3+
35
A880G+ A785G3+
Supporto
audio HD
ALC662
Uscita audio 5.1 canali
Supporto audio High-Definition (HD)
ALC662
Uscita audio 5.1 canali
Supporto audio High-Definition (HD)
Alloggio PCI Express Gen2 x16 x1 Alloggio PCI Express Gen2 x16 x1
Alloggi
Alloggio PC I x2 Alloggio PC I x2
Connettore floppy x1 Connettore floppy x1
Connettore IDE x1 Connettore IDE x1
Connettore SATA x4 Connettore SATA x4
Connettore pannello frontale x1 Connettore pannello frontale x1
Connettore audio frontale x1 Connettore audio frontale x1
Connettore output SPDIF x1 Connettore output SPDIF x1
Collettore ventolina C PU x1 Collettore ventolina C PU x1
Collettore ventolina sistema x1 Collettore ventolina sistema x1
Collettore cancellaz ione CMOS x1 Collettore cancellaz ione CMOS x1
Connettore USB x2 Connettore USB x2
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(4 pin)
Connettore alimentazione x1
(4 pin)
Connettore IR del consumatore x1 Connettore IR del consumatore x1
Connettore Porta stampante x1 Connettore Porta stampante x1
Connettori
su scheda
Connettore Porta seriale x1 Connettore Porta seriale x1
I/O
pannello
posteriore
Tastiera / Mouse PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB x4
Connettore audio x3
Tastiera / Mouse PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB x4
Connettore audio x3
Dimension
i scheda
200 mm (larghezza) x 244 mm (altezza) 200 mm (larghezza) x 244 mm (altezza)
Caratterist
iche
speciali
Supporto RAID 0 / 1 / 1+0 Supporto RAID 0 / 1 / 1+0
Sistemi
operativi
supportati
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
