Biostar A880G+ Версия 6.x [6/49] Otherboard

Motherboard Manual

1.5 MOTHERBOARD LAYOUT

USBKB1

HDMI1

VGA1

DVI1

RJ45USB1

AUDIO1

ATXPWR2

BAT1

JUSBV1

JSPDIFOUT1

LAN

Super I/ O

Codec

F_AUDIO1 J_C OM1

J_PRINT1

FDD1

CIR1

PCI1

PCI2

PEX16_1

F_USB2

F_USB1

SYS_FAN1

PANE L1

JUSBV2

SATA1

SATA2

JCMOS1

BIOS

SATA3

SATA4

AMD

SB710

IDE1

ATXPWR1

CPU_FAN1

D3_1DR A

D3_1

DR B

AMD

880G/

785G

Socket AM3

Note: represents the 1■

pin.
