Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
A880G+/TA880G A785G3+
CPU
Socket AM3
AMD Phenom II/ Athlon II processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and Cool=n=Quiet
(Max imum Watt: 125W)
Socket AM3
AMD Phenom II/ Athlon II processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and Cool=n=Quiet
(Max imum Watt: 125W)
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 880G
AMD SB710
AMD 785G
AMD SB710
Super I/O
ITE 8721
Provides the most co mmonly used legacy Super
I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Monitor
ITE's "S mart Guardian" function
ITE 8721
Provides the most commonly used legacy Super
I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Monitor
ITE's "S mart Guardian" function
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 512MB/1GB/2GB/4GB
DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Registered DIMM and ECC D IMM is not
supported
DDR3 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 512MB/1GB/2GB/4GB
DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Registered DIMM and ECC D IMM is not
supported
Graphics
Integrated in AMD 880G Chipset
Max Shared V id eo Memory is 512MB
DVI/HDMI/HDCP/UVD2 support
Integrated in AMD 785G Chipset
Max Shared V id eo Memory is 512MB
DVI/HDMI/HDCP/UVD2 support
IDE
Integrated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
Integrated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specif ic at ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specif ic at ion co mp liant
LAN
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s auto negotiation
Half / Full duplex capability
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s auto negotiation
Half / Full duplex capability
Sound
ALC662
5.1 channels audio out
High Definition Audio
ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 slot x1 PCI Express Gen2 x16 slot x1
Slots
PCI slot x2 PCI slot x2
