A880G+/TA880G/A785G3+
47
A880G+/TA880G A785G3+
HDオーディ
オのサポー
ト
ALC662
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
ALC662
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
PCI Express Gen2 x16スロット x1 PCI Express Gen2 x16スロット x1
スロット
PCIスロット x2 PCIスロット x2
フロッピーコネクタ x1 フロッピーコネクタ x1
IDEコネクタ x1 IDEコネクタ x1
SATAコネクタ x4 SATAコネクタ x4
フロントパネルコネクタ x1 フロントパネルコネクタ x1
フロントオーディオコネクタ x1 フロントオーディオコネクタ x1
S/PDIFアウトコネクタ x1 S/PDIFアウトコネクタ x1
CPUファンヘッダ x1 CPUファンヘッダ x1
システムファンヘッダ x1 システムファンヘッダ x1
CMOSクリアヘッダ x1 CMOSクリアヘッダ x1
USBコネクタ x2 USBコネクタ x2
電源コネクタ(24ピン) x1 電源コネクタ(24ピン) x1
電源コネクタ(4ピン) x1 電源コネクタ(4ピン) x1
消費者IR コネクタ x1 消費者IR コネクタ x1
プリンタポートコネクタ x1 プリンタポートコネクタ x1
オンボード
コネクタ
シリアルポートコネクタ x1 シリアルポートコネクタ x1
背面パネル
I/O
PS/2キーボード / マウス x1
HDMIポート x1
VGAポート x1
DVI-Dポート x1
LANポート x1
USBポート x4
オーディオジャック x3
PS/2キーボード / マウス x1
HDMIポート x1
VGAポート x1
DVI-Dポート x1
LANポート x1
USBポート x4
オーディオジャック x3
ボードサイ
ズ
200 mm (幅) X 244 mm (高さ) 200 mm (幅) X 244 mm (高さ)
特殊機能
RAID 0 / 1 / 1+0 のサポート RAID 0 / 1 / 1+0 のサポート
OSサポート
Windows XP / Vista / 7
Biostarは事前のサポートなしにOSサポートを追加ま
たは削除する権利を留保します。
Windows XP / Vista / 7
Biostarは事前のサポートなしにOSサポートを追加ま
たは削除する権利を留保します。
2010/11/25
