A770E3+
9
B. Memory Capacity
DIMM Socket
Location
DDR3 Module
Total Memory Size
DIMMA1 512MB/1GB/2GB/4GB
DIMMB1 512MB/1GB/2GB/4GB
DIMMA2 512MB/1GB/2GB/4GB
DIMMB2 512MB/1GB/2GB/4GB
Max is 16GB.
C. Dual Channel Memory installation
Please refer to the following requirements to activate Dual Channel function:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status DDR3_A1 DDR3_A2 DDR3_B1 DDR3_B2
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
The DRAM bus width of the memory module must be the same (x8 or
x16)
Note:
Memory module must be installed in DDR3-A2 or DDR3-B2 to boot the
system.
