Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS 1
USB1
RJ45USB1
AUDIO1
COM1
JUSBV1
ATXPWR2
ATXPWR1
LAN
Codec
Super I/O
PEX1_1
PEX16_1
PEX1_2
PCI3
PCI2
PCI1
F_AUDIO1
J_PR INT 1
FDD1
JSPD IFOUT1
JUSBV2
F_USB1 F_US B2
PAN EL1
SYS_FAN1
SATA1 SATA3 SATA5
SATA2 SATA4 SATA6
BIOS
JCMOS1
BAT
AMD
SB710
IDE1
DDR3_A1
DDR3_A2
DDR3_B2
DDR3_B1
CPU_FAN1
Socket AM3
AMD
760G
Note: represents the 1■
st
pin.
