TA790GX A3+ BIOS Manual
9
Supe r IO Conf igur a tio n
BIOS S ETUP UTILITY
Advanced
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Allo ws BIOS to E nable
or D isable Flopp y
Cont roller
Confi gure ITE8718 Super IO Chi pset
Onboa rd Floppy Con troller [ Enabled]
Keybo ard PowerOn [ Disabled]
Mouse PowerOn [ Disabled]
Resto re on AC Powe r Loss [ Power Off]
Onboard Floppy Controller
Select enabled if your system has a floppy disk controller (FDC) installed on the
system board and you wish to use it. If you installed another FDC or the system uses
no floppy drive, select disabled in this field.
Options: Enabled (Default) / Disabled
Keyboard Pow erOn
This item allows you to control the keyboard power on function.
Options: Disabled (Default) / Specific Key / Stroke Key
Specific Key Enter
This item will show only when Keyboard PowerOn is set “Specific Key.”
Stroke Keys Selected
This item will show only when Keyboard PowerOn is set “Stroke Key.”
Options: Ctrl+F1 (Default) / Wake Key / Power Key / Ctrl+F2 / Ctrl+F3 /
Ctrl +F4 / Ctrl+F5 / Ctrl+F6
