TA790GX A3+ BIOS Manual
14
Wake Up by PCI
Enable / Disable PCI to generate a wake event.
Options: Enabled (Default) / Disabled
USB Configuration
This item shows the USB controller and using USB device information.
BIOS S ETUP UTILITY
Advanced
vxx.xx (C)C opyright 198 5-200x, Amer ican Megatre nds, Inc.
S elect Screen
S elect Item
C hange Option
G eneral Help
S ave and Exit
E xit
+-
F1
F1 0
ES C
Enab les support for
lega cy USB. AUTO
opti on disables
lega cy support i f
no U SB devices a re
conn ected.
USB C onfiguration
USB D evices Enable d:
Modul e Version - 2 .24.3-13.4
Legac y USB Support [ Enabled]
USB 2 .0 Controller Mode [ HiSpeed]
BIOS EHCI Hand-Off [ Enabled]
> USB Mass Storage Device Conf iguration
Legacy USB Support
This item determines if the BIOS should provide legacy support for USB devices
like the keyboard, mouse, and USB drive. T his is a useful fe ature when using such
USB devices with operating systems that do not natively support USB (e.g.
Microsoft DOS or Windows NT).
Options: Enabled (Default) / Disabled
USB 2.0 Controller Mode
This item allows you to select the operation mode of the USB 2.0 controller.
Options: HiSpeed (Default) USB 2.0-480Mbps
FullSpeed USB 1.1-12Mbps
BIOS EHCI Hand-Off
This item allows you to enable support for operating systems without an EHCI
hand-off feature.
Options: Enabled (Default) / Disabled
