TA790GX A2+/TA790GX A2+ SE/TA790GX 128M
3
SPEC
Floppy connector x1 Each connector supports 2 Floppy drives
Printer Port connector x1 Each connector supports 1 Printer port
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connector x1 Supports CD audio-in function
S/PDIF out connector x1 Supports digital audio out function
S/PDIF in connector x1 Support digital audio in function
CPU Fan header x1 CPU Fan power supply (with Smart Fan function)
System Fan h eader x2 System Fan Power supply
CMOS clear header x1 Restore CMOS data to factory default
USB connector x3 Each connector supports 2 front panel USB ports
Serial port Connector x1 Connects to RS-232 Port
Power Connector (24pin) x1 Connects to Power supply
On Board
Connector
Power Connector (4pin) x2 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
HDMI port x1
VGA port x1
DVI-D port x1
LAN port x1
USB Port x4
Audio Jack x6
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to HDTV
Connect to D-SUB monitor
Connect to DVI monitor
Connect to RJ-45 ethernet cable
Connect to USB devices
Provide Audio-In/Out and microphone connection
Board Size 225 mm (W) x 305 mm (L) ATX
OS Support
Windows XP / VISTA
Biostar Reserves the right to add or remove support
for any OS With or without notice.
