TA790GX3 A2+ BIOS Manual
21
5 Chipset Menu
This submenu allows you to configure the speci fic features of the chipset installed on
your system. This chipset manage bus speeds and access to system memory
resources, such as DRAM. It also coordinates communications with the PCI bus.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Series
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Options for NBAdvanced Chipset Settings
> AMD 780 Configuration
> OnBoard Peripherals Configurati on
> SouthBridge Configuration
Exit
SouthBridge Co nfig uration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
OHCI HC(Bus 0 Dev 18 Fn 0) [Ena bled]
OHCI HC(Bus 0 Dev 18 Fn 1) [Ena bled]
EHCI HC(Bus 0 Dev 18 Fn 2) [Ena bled]
OHCI HC(Bus 0 Dev 19 Fn 0) [Ena bled]
OHCI HC(Bus 0 Dev 19 Fn 1) [Ena bled]
EHCI HC(Bus 0 Dev 19 Fn 2) [Ena bled]
OHCI HC(Bus 0 Dev 20 Fn 5) [Ena bled]
OnChip SATA Channel [Ena bled]
OnChip SATA Type [Nat ive IDE]
SATA IDE Combined Mode [Ena bled]
Power Saving Features [Dis abled]
> SB Azalia Audio Configuration
SB CIM Version
Options for SB HD Azal
