TA790GX3 A2+ BIOS Manual

SureBoot Timeout

This item allows you to control the SureBoot timeout.

Options: 4 Seconds (Default) / 1 Second / 2 Seconds / 3 Seconds

Advanced Clock Calibration

This item allows you to control the advanced clock calibration.

Options: Disabled (Default) / Auto / All Cores / Per Core

Value (All Cores/Core 0/Core 1/Core 2/Core 3)

Options: +2% (Default) / -12% ~ +12& with an interval of 2%.

GFX Engine Clock Override

This item allows you to control the internal GFX engine clock override function.

Options: Disabled (Default) / Enabled
