Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
A780G M2+ SE/A780V M2+ SE A740G M2+ SE
CPU
Socket AM2+ / AM2
AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 /
Sempron / Phenom processors
(95W CPU is recommended)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and PowerNow
Socket AM2+ / AM2
AMD Athlon 64 / Athlon 64 FX / Athlon 64 x2 /
Sempron / Phenom processors
(95W CPU is recommended)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 2.0 and PowerNow
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Support HyperTransport 2.0
Supports up to 2.0 GT/s Bandwidth
Chipset
AMD 780G (A780G M2+ SE)
AMD 780V (A780V M2+ SE)
AMD SB700
AMD 740G
AMD SB700
Super I/O
ITE 8718F
Provides the most co mmonly used legacy Super
I/O functionality
Low Pin Count Interface
Environment Control init iatives
H/W Monitor
ITE's "S mart Guardian" funct ion
ITE 8718F
Provides the most commonly used legacy Super
I/O functionality
Low Pin Count Interface
Environment Control init iatives
H/W Monitor
ITE's "S mart Guardian" funct ion
Main
Memory
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (for AM2+ CPU only)
Registered DIMM and ECC D IMM is not
supported
DDR2 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (for AM2+ CPU only)
Registered DIMM and ECC D IMM is not
supported
Graphics
ATI Radeon HD 3200 (A780G M2+ SE)
ATI Radeon HD 3100 (A780V M2+ SE)
Max Shared V id eo Memory is 512 MB
DX10/HDCP support
Hybrid CrossFireX support
UVD support (for A780G M2+ SE only)
ATI Radeon HD 2100
Max Shared V id eo Memory is 512 MB
HDCP support
IDE
Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Vers ion 2.0 spe cific at ion co mp liant
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Vers ion 2.0 spe cific at ion co mp liant
LAN
Realtek RTL 8111C (A780G M2+ SE)
Realtek RTL 8102EL (A780V M2+ SE)
10 / 100 /1000 Mb/s auto negotiation (A780G
M2+ SE)
10 / 100 Mb/s auto negotiation (A780V M2+ SE)
Half / Full duplex capability
Realtek RTL 8102EL
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
