Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS1
JUSB1
JUSBLAN1
JAUDIOF1
Codec
JCDIN1
Super I/O
JCOM1
JUSB3 JUSB2
JSFAN1
JPANEL1
SATA3
SATA4
SATA2
SA TA 1
FDD1
IDE1
JATXPWR1
JCFAN1
Socket AM2+
LAN
PCI1
PCI2
PEX1_1
PE X16_ 1
JSPDI F_OUT1
AMD
SB700
JCMOS1
JATXPWR2
VGA
DIMMA1
DIMMB1
BIOS
DVI
JAUDIO1
JPRNT1
JUSBV2
JUSBV1
SATA5
SATA6
JUSB4
AMD
780G/
780V/
740G
BAT1
JKBV1
Note: represents the 1■
st
pin.
