Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+ / AM2
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64 x2
/ Sempron / Phenom processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and Cool=n=Quiet
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 780G
AMD SB700
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Monitor
ITE's "S mart Guard ian" funct ion
Main
Memory
DDR2 DIMM Slots x 4
Max Memory Capacity 8GB
Each DIMM supports 256/512MB/1GB/2GB
DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (for AM2+ CPU only)
Registered DIMM and ECC DIMM is not supported
Graphics Integrated in A MD 780G Ch ipset
Max Shared V ideo Memory is 512 MB
DX10 support
HDCP / UVD support
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 spec if icat ion co mpliant
LAN Realtek RTL 8111C
10 / 100 / 1000 Mb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1 channels audio out
High Definition Audio
PCI Express Gen2 x16 slot x1 Supports PCI-E Gen2 x16 expansion cards
PCI Express Gen2 x1 slot x1 Supports PCI-E Gen2 x1 expansion cards
Slots
PCI slot x2 Supports PCI expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
On Board
Connector
Front Audio Connector x1 Supports front panel audio function
