Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS1
JUSB1
JUSBL AN1
JAUDIOF1
Codec
JC DIN1
Super I/O
JCOM1
JUSB4
JUSB3 JUSB2
JSFAN1
JPANEL1
SATA3
SATA4
SATA2
SATA1
FDD1
IDE1
JATXPWR1
JCFAN1
Socket AM2+
AMD
780G
LAN
PC I1
PC I2
PEX1_1
PEX16_ 1
JSPDIF_OUT1
AMD
SB700
JCMOS1
JATXPW R2
VGA
DIMMA1
DIMMB1
BIOS
DVI
JAUDIO1
JPRNT1
JU SBV 2
JUSBV1
SATA5 SATA6
BATTERY
DIMMA2
DIMMB2
Note: represents the 1■
st
pin.
