TA770 A2+ SE
27
Notices:
1. Not all types of AMD CPU perform above overclock setting ideally; the difference will be based
on the selected CPU model.
B. Memory Integration Test (M.I.T.)
This function is under “Overclocking Navigator Engine” item.
MIT allows users to test memory compatibilities, and no extra devices or
software are needed.
Step 1
The default setting under this item is “Disabled”; the condition parameter should
be changed to “Enable” to proceed this test.
BIOS SE TUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C )Copyright 1985-200x, American Megatrends, Inc.
Select Scree n
Select Item
Change Optio n
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Ser ies Settings
WARNI NG: Setting wrong values in below sections
may cause system to malfunction.
===== ====== Automate OverClock System ===========
===== ======= Manual OverClock System ============
OverC lock Navigator [Normal]
Auto OverClock System [V6-Tech Engine]
CPU O ver Voltage [StartUp]
Memor y Over Voltage [1.95V]
Chips et Over Voltage [1.15V]
HT Ov er Voltage [1.20V]
CPU F requency [200]
> CPU FID/VID Control
> Mem ory Configuration
> DRA M Timing Configuration
> Hyp er Transport Configuration
Integ rated Memory Test [Disabled]
Exit
Optio ns
Enabled
Disabled
↓
BIOS SE TUP UTILITY
Main Advanced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C )Copyright 1985-200x, American Megatrends, Inc.
Select Scree n
Select Item
Change Optio n
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Ser ies Settings
WARNI NG: Setting wrong values in below sections
may cause system to malfunction.
===== ====== Automate OverClock System ===========
===== ======= Manual OverClock System ============
OverC lock Navigator [Normal]
Auto OverClock System [V6-Tech Engine]
CPU O ver Voltage [StartUp]
Memor y Over Voltage [1.95V]
Chips et Over Voltage [1.15V]
HT Ov er Voltage [1.20V]
CPU F requency [200]
> CPU FID/VID Control
> Mem ory Configuration
> DRA M Timing Configuration
> Hyp er Transport Configuration
Integ rated Memory Test [Enabled]
Exit
Optio ns
Enabled
Disabled
Step 2
Save and Exit from CMOS setup and reboot the system to activate this test.
Run this test for 5 minutes (minimum) to ensure the memory stability.
Step 3
When the process is done, change the setting back from “Enable” to “Disable”
to complete the test.
