Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2 / AM2+
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64 X2
/ Sempron / Phenom processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and PowerNow
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 770
AMD SB700
Super I/O
ITE 8718F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control initiatives ,
H/W Monitor
Fan Sp eed Contro ller
ITE's "S mart Guard ian " funct ion
Main
Memory
DIMM Slots x 4
Each DIMM supports 512MB/1GB/2GB/4GB
DDR2
Max Memory Capicity 16GB
Dual Channel Mode DDR2 memory modu le
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not supported
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II AMD SB700
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specificat ion co mp liant.
RAID 0,1,1+0 support
LAN Realtek RTL 8111C
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound ALC662
5.1channels audio out
Supports HD Audio
PCI slot x3 Supports PCI expansion cards
PCI Express Gen2 x16 slot x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI Express x1 slot x2 Supports PCI-E x1 expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
Printer Port connector x1 Each connector supports 1 Printer port
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
On Board
Connector
Front Panel Connector x1 Supports front panel facilities
