Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
USB1
RJ45USB1
VGA1
DVI1
AUDIO1
JUSBV1
AT X PWR2
F_AUDIO1
LAN
Super
I/O
Codec
ATXPWR1
CPU_FAN1
PEX16_1
PCI1
PCI2
FDD
F_PRINT1F_COM1
IDE1
JUSBV2
PANEL 1
F_USB2
F_USB1
SATA1
SATA2
SYS_FAN1
SATA3
SATA4
BIOS
DIMMA1
DIM MB1
JCMOS1
Socket AM2+
GeForce
8200
BAT1
JSPDIFOUT1
Note: represents the 1■
st
pin.
