MCP6PB M2+/N68S
29
SPEC
Connecteur SATA x2
Chaque connecteur prend en charg e 1 périphériqu e
SATA
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Audio du panneau avant x1 Prend en charge la fonction audio du panneau avant
Embase de ventilateur UC x1
Alimentation électrique du ventilateur UC (avec
fonction de ventilateur intelligent)
Embase de ventilateur système x1 Alimentation électrique du ventilateur système
Embase d'effacement CMOS x1
Connecteur USB x2
Chaque connecteur prend en charge 2 ports USB de
panneau avant
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(4 broches)
Connecteur de Port d'imprimante x1
Chaque connector prend en charge 1 Port
d'imprimante
Connecteur de Port série x1
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port LAN x1
Port USB x4
Fiche audio x3
Dimension
s de la
cart e
170 mm (l) X 235 mm (H)
Fonctionnal
ités
spéciales
Prise en charge RAID 0 / 1
Support SE
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de supprimer le
support de SE avec ou sans préavis.
