11
5V/ 5VSB Selection for USB: JUSBV1/2/3
5V/ 5VSB Selection for KB: JKBV1
Front 1394 Header: J1394A1/ J1394B1/ J1394C1
(Optional)
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V_SB
1
JUSBV1/2/3
1
JKBV1
Pin 1-2 on ==> 5V
Pin 2-3 on ==> 5V
_
SB
JUSB3/4
2
1
Pin1,2 ==> +5V
Pin3,4 ==> Dato(-)
Pin5,6 ==> Dato(+)
Pin7,8 ==> Tierra
Pin9 ==> KEY
Pin10 ==> NA
J1394A1/B1/C1
2
1
Pin1,2 ==> A+/A-
Pin3,4 ==> Ground
Pin5,6 ==> B+/ B-
Pin7,8 ==> +12V
Pin9 ==> KEY
Pin10 ==> NA
