14
Clear CMOS Jumper: JCMOS1
Back Panel Connectors
1
JCMOS1
Pin 1-2 on ==> Normal O
p
eration
(default)
Pin 2-3 on ==> Clear CMOS Data
PS/2
Keybo ard
PS /2
Mouse
COM1
Parallel
Game Port
JPRNT1
JGAME1
JKBMS1
USB
COM1
S
p
ea k e r
Out
Li ne In
Mic
In
JUSB1
COM1
JCOM1
COM1 COM2
JCOM2
12
Front Panel Audio Connector/ Jumper Block
910
Audio line out si
g
nals are routed
to the back
p
anel audio line ou t con nector.
Pin 5 and 6
==>
Pin 9 and 10
12
910
Audio line out and mic in signals are
available for front panel audio connectors.
