Overclock Panel contains the these features:

a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user

the ability to do real-time overclock adjustment.

Warning: Manually overclock is potentially dangerous, especially when the

overclocking percentage is over 110 %. We strongly recommend you verify

every speed you overclock by click the Verify button. Or, you can just click

Auto overclock button and let [ WarpSpeeder™ ] automatically gets the best

result for you.

b. “Recovery Dialog button”: Pop up the following dialog. Let user select a restoring

way if system need to do a f ail-safe reboot.
