BIOSTAR Motherboard
Section 3. K8NHA-M Grand Features
In this section, you shall find all the information about the
motherboard in your computer, including its features, layout,
component index, various jumpers, headers, connectors, and also
the installation guide to help you a quick and correct installation
of your system.
A. Hardware
CPU
* Supports Socket 754.
* Supports the AMD Athlon 64
®
Socket-754 processor start from 3200+/2.0GHz.
* Running at 200/400/600/800 MHz Front Side Bus.
Chipset
* NVIDIA
®
CrushK8S (nForce3 250)
- HyperTransport link to the AMD K8 CPU.
- Supports AGP3.0 8X interface.
- Running at 200/400/600/800 MHz Front Side Bus.
- Single USB 2.0 EHCI/Dual USB 1.1 OHCI, 8 ports.
- Supports S-ATA(n)
- PCI 2.3 interface supporting.
- Supports system and power management.
- AC’97 2.3 interface.
Super I/O
* Chip: ITE IT8712F.
* Low Pin Count Interface.
* Provides the most commonly used legacy Super I/O functionality.
* Environment Control initiatives,
- H/W Monitor
- Fan Speed Controller
- ITE's “Smart Guardian” function
Slots
* Three 32-bit PCI bus master slots.
* One AGP 4X/8X slot.
* One CNR slot. (optional)
