Biostar A10N-9830E Версия 6.0 [4/48] 3 specifications
![Biostar A10N-9830E Версия 6.0 [4/48] 3 specifications](/views2/1712366/page4/bg4.png)
4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
A10N-9830E : AMD® FX-9830P (Quad core 3.0GHz up to 3.7GHz)
A10N-9630E : AMD® A10-9630P (Quad core 2.6GHz up to 3.3GHz)
Memory
Supports Dual Channel DDR4 2133/ 2400
2 x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
2x SATA III Connector (6Gb/s)
1x M.2 (M Key) Socket:
Supports PCI-E 3.0 x2 (16Gb/s) - NVMe/ AHCI SSD & SATA III (6.0Gb/s) SSD
* When PCIE-M2_1 slot is occupied, the SATA2 connector will be disabled.
LAN
Realtek RTL 8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio
USB
4x USB 3.2(Gen1) port (2 on rear I/Os and 2 via internal headers)
4x USB 2.0 port (2 on rear I/Os and 2 via internal headers)
Expansion Slots 1x PCIe 3.0 x16 Slot (x4)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x VGA Port
1x HDMI Port
1x LAN port
2x USB 3.2(Gen1) Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
2x SATA III 6.0Gb/s Connector
1x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.2(Gen1) Header (each header supports 2 USB 3.2(Gen1) ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Serial Port Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7(32/64bit)/ 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.
