Chapter 3 Web Login
Web configuration provides a user-friendly graphical user interface (web pages) to manage your
WRT-414. A WRT-414 with an assigned IP address will allows you to monitor and configure via web
browser (e.g., MS Internet Explorer or Netscape).
1. Open your web browser.
2. Enter the IP address of your WRT-414 in the address field (default IP address is http://192.168.0.1).
3. A User Name and Password dialog box will appear. Please enter your User Name and Password
here. Default User Name and Password are both “admin”. Click OK.
4. Then you will see the WRT-414 main page as below.
The left panel provides four options, Quick Setup, General Setup, Status Information and Tools.
- 5 -
Section Description
Quick Setup Select your Internet connection type and then input the configurations needed
