INDOOR UNIT LINEUP
2019
Slim Ceiling Mounted
Duct Type
Slim design, quietness and
static pressure switching
External static pressure selectable by remote
controller switching make this indoor unit a very
comfortable and flexible model.
10 Pa-30 Pa/factory set: 10 Pa for FXDQ-PB models.
15 Pa-44 Pa/factory set: 15 Pa for FXDQ-NB models.
Only 200 mm in height, this model can be
installed in rooms with as little as 240 mm depth
between the drop-ceiling and ceiling slab.
Only 700 mm in width and 23 kg in weight, this
model is suitable to install in limited spaces like
drop-ceilings in hotels.
1,100 mm in width for the FXDQ63NB model.
200 mm
900 mm
Suction grille*
AIR
AIR
Discharge grille*
Air filter
Suspension bolt*
240 mm
*To be obtained locally
FXDQ-PB and FXDQ-NB models are available in
two types to suit different installation conditions.
FXDQ-PB/NBVE: with a drain pump (750 mm lift)
as a standard accessory
FXDQ-PB/NBVET: without a drain pump
Only 700 mm
200 mm
Great for
hotel use!
Suited to use in drop-ceilings!
750 mm
Ceiling
FXDQ20PB/FXDQ25PB/FXDQ32PB
FXDQ40NB/FXDQ50NB/FXDQ63NB
Low operation sound level
36/34/32
63
35/33/31
50
34/32/30
40
33/31/29
20/25/32
Sound level
(HH/H/L)
FXDQ-PB/NB
(dB(A))
The values of operation sound level represent those for rear-suction operation.
Sound level values for bottom-suction operation can be obtained by adding 5 dB(A).
Values are based on the following conditions:
FXDQ-PB: external static pressure of 10 Pa; FXDQ-NB: external static pressure of 15 Pa.
Control of the airflow rate has been improved
from 2-step to 3-step control.
Ceiling Mounted
Duct Type
Improved ease of installation
Improved ease of maintenance
Middle and high static pressure
allows for flexible duct design
All models are only 300 mm in height, an
improvement over the 390 mm height of
conventional models. The weight of the
FXMQ40P has been reduced from 44 kg to
28 kg.
A DC fan motor increases the external static
pressure capacity range to include middle to high
static pressures, increasing design flexibility.
FXMQ20P/FXMQ25P/FXMQ32P
FXMQ40P/FXMQ50P/FXMQ63P
FXMQ80P/FXMQ100P/FXMQ125P
FXMQ140P
Drain pump is equipped as standard accessory
with 700 mm lift.
Control of the airflow rate has been improved
from 2-step to 3-step control.
700 mm
Ceiling
30 Pa–100 Pa for FXMQ20P-32P
30 Pa–160 Pa for FXMQ40P
50 Pa–200 Pa for FXMQ50P-125P
50 Pa–140 Pa for FXMQ140P
Low operation sound level
300 mm
Easy installation in buildings
with narrow ceiling spaces
Airflow rate can be controlled using a remote
controller during test operation. With the
conventional model, the airflow rate was controlled
from the PC board. It is automatically adjusted to
the range between approximately ±10% of the rated
HH tap airflow for FXMQ20P-125P.
Energy-efficient
The adopted DC fan motor is much more
efficient than the conventional AC motor,
yielding an approximate 20% decrease in
energy consumption. (FXMQ125P)
The drain pan can be detached for easy
cleaning. An antibacterial treatment that uses
silver ions has been applied to the drain pan,
preventing the growth of slime, mould and
bacteria that cause blockages and odours.
(dB(A))
46/45/43
140
42/40/38
63
43/41/39
80/100
41/39/37
50
39/37/35
40
34/32/30
32
33/31/29
20/25
Sound
level
(HH/H/L)
FXMQ-P
44/42/40
125
