For the safety reasons, you are recommended never to touch a high-gain

antenna when it is transmitting or point it at any part of your body.

Please, follow carefully the instructions with your antenna.

Keep antennas away from metal objects/obstructions (heating and air-condi

tioning ducts, large ceiling trusses, building superstructures, and major power

cabling runs).

Use a directional antenna when you establish a link between two buildings.

A directional antenna must be properly aligned to the point at the other

antenna, line-of-sight.

Locate an omni-directional antenna in the middle of the desired coverage area

if possible.

Place the antenna as high as possible to increase the coverage area.

Outdoor antennas should be mounted at a sufcient height to prevent the

radio path from above the obstructions such as trees and buildings.

Antenna towers should keep a safe distance from overhead power lines. The

recommended safe distance is twice the tower height.

3. Using Category 3 or higher UTP or STP cable, connect the LAN port of Mesh

AP to a 10Mbps or 10/100Mbps Ethernet switch, and connect the management

station to switch on the same LAN.

4. Connect the power adapter to the receptor on Mesh AP and plug the other end

to a wall outlet or power strip.

Note

1. ONLY use the power adapter supplied with the Mesh AP. Other-

wise, the product may be damaged.

2. The LAN Port, LAN Port#1 or Public Port of Mesh AP supports

802.3af POE. The pins for supplying the electricity are 1, 2, 3, 6.

If the Mesh AP is powered from POE, you can skip step 4 above.

3. Connect 802.3af PoE to both LAN and Public of your Mesh AP

will damage your device permanently.
