7
WBT-1000A
Package Contents
The following items should be included:
Outdoor Wireless Amplier Unit x 1
DC Injector Unit x 1
Mounting Kit x 1
30 cm male RP-SMA to male N type cable x 1
Quick Installation Guide x 1
Power Adapter x 1
If any of the above items are damaged or missing, please contact your dealer
immediately.
Specications
Operating Range
5150 ~ 5850 MHz
Operating Mode
Bi-directional, half-duplex, auto-switching via carrier
sensing
Connector Type
N-type, female (50 ohm)
Input power
0~15dbm
Warning: Input power more than 15 dBm may
breakdown the power amplier.
Output Power
1W (30 dBm)
Receiver Gain
15 dB typical
Noise Figure
5 dB typical
Frequency Response
± 1 dB over operating range
DC Power input
9V DC, 2.0 A
Operating Temp.
-20 to +70°C
Operating Humidity
Up to 95% relative humidity
Material
Cast Aluminum
Lightning Protection
Direct DC ground at antenna connector
DC Surge Protection
At DC input from transmission cable
LED
Transmit Active (Green)
Outdoor Unit (cm)
11.5cm (L) x 6.5cm (W) x 4.8cm (H)
DC Injector (cm)
10.2cm (L) x 3.6cm (W) x 2.6cm (H)
Weight
345g (Booster) / 96g (DC Injector)
l
l
l
l
l
l
