4
1.3 Specification
Product IEEE802.11g Wireless PCMCIA Card
Model Name WL-3560
Attachment Interface PC CardBus 32-bit compliant
LED Indicators Two Link/Act
Operating Frequency /
Channel
2.412~2.462GHz (FCC, USA & Canada) / 11 Channels
2.412~2.4835GHz (TELEC, Japan) / 14 Channels
2.412~2.472GHz (ETSI, Europe) / 13 Channels
RF Modulation Direct Sequence Spread Spectrum (DSSS) Technology
(OFDM, CCK, QPSK, BPSK)
RF Output Power 16dBm (typical)
Sensitivity
802.11g: -66dBm @ PER<8%, 54 Mbps
802.11b: -82dBm @ PER<8%, 11 Mbps
Data Rate
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps with auto-
rate fall
back
802.11b: 11, 5.5, 2, 1 Mbps with auto-rate fall back
Media Access Protocol CSMA/CA + ACK
Antenna Built-in patch antenna
Working Mode
Ad-Hoc, Infrastructure
Dimension (mm)
119 x 54 x 12 mm
Humidity
0-95%, non-condensing (Operating and storage)
Temperature
0 – 55 degree C (Operating), -10~70 degree C (Storage)
Compatibility
Windows 98SE/ME/2000/XP/Server 2003
Management
Utility or Windows XP built-in management interface
Electromagnetic Compatibil-
ity
FCC Part 15 class B, CE Mark, ETS 300 328
1.4 Package Contents
Before installation, please check the items of your package. The package should include the
following items:
WL-3560 x 1
Quick Installation Guide x 1
Drivers and User’s Manual CD x 1
If any of the above items are missing, contact your supplier as soon as possible.
1.5 Minimum System Requirements
Before installation, please check the following requirements with your equipment.
• Operating System: Windows 98/Me/2000/XP/Server 2003
• PC with CD-ROM driver
• One vacant PCMCIA slot
