Fan removal guide
29
Primera Series PM01-RGB / PM01-FX
Entnehmen Sie den Hauptfilter, Lösen Sie die Befestigungsschrauben des Lüfters, nehmen Sie sie heraus
Retire filtro principal, Suelte los tornillos que soportan los ventiladores para retirarlos
Rimuovere il filtro principale, Svitare le viti che fissano le ventole per rimuoverle
Remove main filter, Unscrew screws holding the fans to remove them
Снимите главный фильтр, Чтобы извлечь вентиляторы, отверните винты их крепления
주 필터를 분리합니다,팬을 고정하는 나사를 풀어 팬을 분리합니다
移除主濾網,卸除固定風扇的螺絲,卸除風扇
移除主滤网,卸除固定风扇的螺丝,卸除风扇
メインフィルターを取り外します,ファンを固定しているネジを外して、取り外します
Enlevez le filtre principal, Dévissez les vis des ventilateurs pour les enlever
