32
03
04
Lösen Sie mit einem kleinen
Schraubendreher die
Schrauben, die die
Geschwindigkeitsschalter
halten, und nehmen Sie diese
aus dem Gehäuse.
A l’aide d’un petit tournevis,
enlevez les vis fixant les
commutateurs de vitesse pour
le retirer du châssis
Usando un destornillado
pequeño, suelte los tornillos
que sujetan los interruptores
de velocidad para
retirarlos de la carcasa
Utilizzando un piccolo
cacciavite,allentare le viti che
fissano gli interruttori di velocità
per rimuoverli dal case
Using a smaller screw driver,
release screws holding
the speeds switches to remove
it from the case
Чтобы снять с корпуса
переключатели скорости
вентиляторов,
с помощью небольшой
отвертки отверните винты
их крепления
소형 스크루드라이버를 사용하
여 속도 스위치를 고정하는
나사를 풀어 스위치를 케이스에서
분리합니다.
卸除固定轉速切換開關的螺絲,
將轉速切換開關由前板的洞穿
出機殼(提醒您,應該要換更小
的螺絲起子)
卸除固定转速切换开关的螺丝,
将转速切换开关由前板的洞穿
出机壳(提醒您,应该要换更小
的螺丝起子)
小さいドライバーを使って、回転
数スイッチを固定しているネジ
をケースから取り外します
Gehen Sie umgekehrt vor,um die Lüfter wieder zu
installieren.
Suivez les étapes ci-dessus dans l'ordre inverse pour
réinstaller les ventilateurs
Siga los pasos anteriores de forma inversa para
reinstalar los ventiladores
Attenersi alle istruzioni di cui sopra in ordine inverso
per reinstallare le ventole
Follow the above steps in reverse to reinstall the
fans
Для установки вентиляторов на место повторите описанные
выше действия в обратном порядке
팬을 도로 설치하려면 위의 단계를 역순으로 수행하십시오.
依照相反的順序安裝回去
依照相反的顺序安装回去
ファン取り付けには以上のステップを逆順に行います。
