SilverStone SST-RV05WB-W [4/44] Introduction

SilverStone SST-RV05B-W [4/44] Introduction
1
Material
Model
Motherboard
Drive Bay
Cooling System
Expansion Slot
Front I/O Port
Power Supply
Expansion Card
Limitation of CPU cooler
Dimension
Plastic outer shell, steel body
SST-RV05B (black) / SST-RV05B-W (black + window)
SSI-CEB, ATX, Micro-ATX
Exposed Slim slot-loading optical x 1
Internal 3.5" x 2, 2.5” x 2
Bottom 2 x Air Penetrator 180mm fan 600/900/1200rpm, 17/25/34dBA
Downward compatible with 3 x 120mm fan or 2 x 140mm fan
Top 120mm fan slot x 1
7
USB 3.0 x 2 , audio x 1 , MIC x 1
Optional PS2 (ATX)
Compatible with 12.3” long, width restriction – 6.57”
162mm
242 mm (W) x 529 mm (H) x 498 mm (D)
The RAVEN RV05, the fifth edition in the exciting RAVEN enthusiasts
chassis series continues the tradition of breaking and evolving the
standards of desktop PC design. With a bold move that sees the
removal of all 5.25” drive bays, the RAVEN team engineers again saw
the opportunity to re-utilize the 90 degree rotated design. Previous
RAVEN models with 90 degree layout often had to compromise on
space efficiency due to fixed length of the motherboard in rotated
orientation. The elimination of 5.25” bays solves this issue naturally
and enables RV05 to be even more balanced in terms of design than
if the same were done to a traditionally-layout case.
With most of the wasted space eliminated from RV05, engineers were
thus able to better optimize the case for the most important
performance-affecting components such as CPU and GPUs.
The result is an expertly-engineered ATX chassis that is just as capable
in terms of compute power and heat dissipation as the first RAVEN
chassis, the RV01, but in half the size. Equipped with latest revision
Air Penetrator AP181 fans that include three speed switches and
modern touches such as externally removable filters and tool-less
panels, the RV05 has everything that PC enthusiasts could wish
for in a compact, high performance computer case that is not only cool
and quiet, but also easy to build and maintain. For those not wanting
to constantly step up in case size to obtain top-level performance,
the RAVEN RV05 is the perfect solution and it may also represent a
glimpse into the future of mainstream enthusiasts PC design.
Introduction
Specification
