Planet ICA-HM125 [3/12] System requirements

Chapter 1. Introduction

Thank you for purchasing the PLANET 2-MegaPixel IP Camera, ICA-HM125, is the

state of the art design using the highest resolution for high quality image capture.

Compared with VGA cameras with 640x480 pixel resolution, the ICA-HM125 deliver

clear image with dual H.264/M-JPEG stream video up to UXGA (1600 x 1200

pixels). The ICA-HM125 offers high exibility to be applied in various kinds of IP

surveillance environment as it has built-in ICR (IR-cut lter Removable) for day /

night surveillance and is compatible with IEEE 802.3af PoE (Power over Ethernet)

for easy installation without concerning the outlet / socket locations. Network and

analog video output interfaces are equipped for exible viewing and recording

implementations. The ICA-HM125 is also designed with the removable CS mount

lens that can be customized with auto-iris, wide angle, vari-focal or other types of

lens as required.

The PLANET IP Camera support multiple video prole can stands for simultaneously

video streams. The IP Cameras can generate H.264 and M-JPEG streaming

simultaneously to different clients. Moreover, the resolution can be different from

one client to another. This state-of-art design is considerable to t in various

network environments.

1.1 Before Installation

Before installation, please be sure to read this quick installation guide and user’s

manual (CD) carefully to complete machine installation. This guide shows how to

quick set up the IP Cameras, unless model name specied terms “IP Camera” will

be used for this model.

1.2 System Requirements

The IP Camera can be monitoring on all of Windows operating system that with

suggest system requirment below in order to get better video performance when

resolution up to 2 megapixel.

CPU Intel

Core2 Duo E5300 2.6GHz

RAM 1 GB

Video RAM 128MB

Display Chip nVIDIA GeForce 8500GT or ATI Radeon HD 4350 or above

Display Resolution 1024 x 768 24bits

Operating System

Windows2000 SP4 / Windows XP Pro SP2 / Windows 2003

/ Vista

DirectX 9.0c or above

Network Wired Ethernet 100Base-TX
