2.3 ICA-HM125 Installation

Step 1. Prepare a PC with Ethernet link to the network

Step 2. Connect an Ethernet cable

Connect LAN port (RJ-45) of the IP Camera to a network switch. When

this switch is a PoE device, you can ignore the next step.

Note

If there has an IEEE 802.3af PoE switch in your network, you

can connect the IP Camera LAN cable to this PoE switch to obtain

power. The power adapter is unnecessary when IP Camera is

connected to a PoE switch.

Step 3. Attach the power supply

Plug in power adapter to IP Camera and connect another end to power

outlet.

Note

Only use the power adapter supplied with IP Camera otherwise, the

product may be damaged.

Step 4. Check LED status

The Power LED is dened to identify IP Camera status. When IP Camera

booting the LED will be ashing and while IP Camera is ready the LED will

be green.

Step 5. Attach BNC connector and speaker to IP Camera (option)

Connect the video BNC connector to a monitor set if necessary check IP

Camera viewing angle and focus. And if user needs not only video stream

but also audio stream, then the speaker should be attached to IP Camera.
