54
Restore Setting: Click the “Browse” button to locate the saved backup file and
then click the “Restore Setting” button. The settings will be
restored to the previous configuration.
Firmware upgrade: The device supports new firmware upgrade.
1. Close all other application programs which are not
necessary for firmware update.
2. Make sure that only you access this device at this moment
3. Disable Motion Detection function.
4. Select “Firmware name”
5. Select the Firmware binary file.
Note: That it must make sure that the Firmware only applies to this device, once update, it
will be burned into FLASH ROM of system.
6. Once the firmware file was selected, select “Upgrade”.
7. The upgrade progress information will be displayed on the
screen.
8. A message will be shown while the firmware upgraded.
Once the upgrading process completed, the device will
reboot the system automatically.
9. Please wait for 80 seconds, and then you can use PLANET
IPWizard II to search the device again.
Warning!!! The download firmware procedure cannot be interrupted. If the power
and/or network connection are broken during the download procedure, it might
possibly cause serious damage to the device.
Please be aware that you should not turn off the power during updating the firmware
and wait for finish message.
Furthermore, do not try to upgrade new firmware if it’s not necessary.
System Restart: The device is restarted without changing any of the settings.
