contrast, hue and sharpness properly.
Image flickers.
z
Wrong power line frequency makes images flicker. Make sure the
50 or 60Hz format of your device.
z
If the object is dark, the image will flicker. Make the condition
around the Camera brighter.
Miscellaneous
Can not play the recorded ASF file Please installed Microsoft®’s DirectX 9.0 or later and uses the
Windows Media Player 11.0 or later to play the AVI filed recorded by
the Device.
89
