Daikin REYQ8PY1B [5/19] Read the following cautions carefully and use your equipment properly
![Daikin REYQ10PY1B [5/19] Read the following cautions carefully and use your equipment properly](/views2/1713624/page5/bg5.png)
English 1
REYQ8PY1B
REYQ10PY1B
REYQ12PY1B
REYQ14PY1B
REYQ16PY1B
VRV
III
System air conditioner
Operation manual
CONTENTS
1. SAFETY CAUTIONS....................................... 1
2. SPECIFICATIONS........................................... 3
3. WHAT TO DO BEFORE OPERATION ............ 4
4. REMOTE CONTROLLER AND COOL/HEAT
SELECTOR: NAME AND FUNCTION OF
EACH SWITCH AND DISPLAY....................... 4
5. OPERATION RANGE...................................... 5
6. OPERATION PROCEDURE ........................... 5
7. OPTIMUM OPERATION ................................. 9
8. SEASONAL MAINTENANCE.......................... 9
9. FOLLOWING SYMPTOMS ARE NOT AIR
CONDITIONER TROUBLES......................... 10
10. TROUBLE SHOOTING ................................. 12
1. SAFETY CAUTIONS
Read the following cautions carefully and
use your equipment properly.
There are two kinds of safety cautions and tips listed
here as follows:
WARNING .......Improper handling can lead to
such serious consequences as
death or severe injury.
CAUTION ........Improper handling can lead to
injury or damage. It could also
have serious consequences
under certain conditions.
NOTE
Keep this operation manual handy so that you
can refer to them if needed.
Also, if this equipment is transferred to a new user,
make sure to hand over this operation manual to the
new user.
WARNING for operation
• Do not expose yourself directly to the cool air
currents too long nor allow the air in the
room to become too cold.
Doing so may make you feel sick or damage your
health.
• Do not put your fingers, rods, or other objects into
the air inlet or outlet while the fan is in operation.
Injury may result because the fan is rotating at
high speed.
• Flammable if refrigerant leaks.
The refrigerant used in the air conditioner is safe
and should not normally leak, but if it does leak
into a room, it will emit a noxious gas if it comes in
contact with any kind of heater, stove, or other sim-
ilar objects.
Turn off any combustible heating devices, ventilate
the room, and contact the dealer where you pur-
chased the unit.
When repairing a refrigerant leak, have a service
engineer check that the repair has been per-
formed properly before running the unit again.
• Use only fuses of the correct capacity if a fuse
load switch is being used.
Using wires may cause breakdown and fire.
• Do not disassemble, modify, or repair.
This may cause water leakage, electric shock, or
fire. Only your dealer should attempt such proce-
dures.
• If anything unusual occurs (e.g., a burning
smell), stop the operation of the air conditioner
and shut off the power.
Leaving the unit running under such circum-
stances may cause breakage, electrical shock, or
fire.
Contact your dealer.
• Consult the dealer if the air conditioner sub-
merges owing to a natural disaster, such as a
flood or typhoon.
Do not operate the air conditioner in that case, or
otherwise a malfunction, electric shock, or fire may
result.
• Do not operate the air conditioner when using
a room fumigation - type insecticide.
Failure to observe could cause the chemicals to
become deposited in the unit, which could endan-
ger the health of those who are hypersensitive to
chemicals.
CAUTION for operation
• Do not use the air conditioner for purposes
other than air conditioning.
Do not use the air conditioner to keep food, ani-
mals, plants, precision instruments, or works of art
cool.
Otherwise, their quality deterioration will result.
• Do not remove the fan guard of the outdoor
unit.
The exposed fan may cause injury.
• Do not place items under the indoor unit which
may be damaged by water.
Drips may fall in the following cases: 80% or higher
in humidity, clogged drain outlet, or foul air filter.
01_EN_3P201178-2B.fm Page 1 Wednesday, April 25, 2007 3:51 PM
