3.3 Front Panel

Focus Ring

Audio LED

LAN LED

WLAN LED

Microphone

Power LED

Indicators Description

Focus Ring

User could use this ring to adjust focus

manually.

LAN LED

The LED indicates LAN activity.

It be ashing while network accessing via

Ethernet.

WLAN LED

(ICA-M220W only)

The LED indicates the wireless accessing of the

PT Internet Camera.

Light be ashing while transferring via wireless

LAN. If be ashing at low speed once a second

indicated that waiting for WPS connection form

AP.

Microphone

The Camera has built-in an internal

microphone. This microphone is hidden in the

pinhole located on the front panel.

Audio LED

The LED indicates the audio activity, when it is

ashing while speak function enable, if volume

adjust to 0 the function will be disable.

Power LED The LED is used to indicate DC power status.
