2.3 Physical Installation

1. Connect an Ethernet cable

Connect one end of an Ethernet cable to the LAN port located on the IP

Camera bottom panel and attach the other end to the network device

(hub or switch).

2. Attach the external power supply

Connect the provided power adapter to the IP Camera’s connector

labeled “12V DC” on the bottom panel.

Note

1. Please use the power adapter that is bundled in

the package. Using a power supply with a different

voltage rating will damage and void the warranty for

this product.

2. For ICA-107P, either powered from AC adapter, or

from PoE is allowed.

3. Check the LEDs

The power LED should be on.

2.4 IP Camera Admin Software

Follow the steps below to install the initial utility. The following

installation is implemented in Windows XP and the installation

procedure is similar to Windows 2000.

1. Insert the bundle CD disk into your CD-ROM drive. A welcome web

page should open with your default browser. If not, please double

click on the “default.htm” in the CD.

2. Please click the IP Camera model name.

3. Click on the hyperlink “IP Camera initial utility”.
