Planet ICA-108 [12/36] Physical installation

3.5 Physical Installation

1. Connect an Ethernet cable

 ConnecttheLANcableonthePTInternetCameratothenetworkdevice(hubor

switch).

Note

If there has an IEEE802.3af PoE switch in your network, you can

connect the ICA-230/M230 LAN cable to this PoE switch to obtain

power. The power adapter is unnecessary when ICA-230/M230 is

connected to a PoE switch.

2. Check the LED (Front Panel)

 TheLEDisdenedtoidentifyLANconnectiontype.WhenLANportisconnected,

theLEDwillbegreen.

3.PlacethePTInternetCameraonthetableorxitontoceilingorwall

 UsescrewstoxthePTInternetCameraontotheceilingorwall.Youcouldalso

putthePTInternetCamerainthetabledirectly.

4.Attachthepowersupply

Plug in power adapter and connect to power source. After power on, PT Internet

Camera will start to operate.

Note

Only use the power adapter supplied with PT Internet Camera.

Otherwise,theproductmaybedamaged

The power adapter is unnecessary when ICA-230/M230 is connected

to a PoE switch. Otherwise, the product may be damaged when

ICA-230/M230 is connected to a PoE switch and power adapter

simultaneously.

5.AttachSpeakertoPTInternetCamera(option)

 If user needs not only video stream but also audio stream, then the speaker

shouldbeattachedtoPTInternetCamera.
