50 Meter Infrared Camera – CAM-IR552

Packet Content

CAM-IR552

Screw kit x 1

Quick Installation Guide x 1

Installation

1.PleasextheCAM-IR552toasuitablelocationwiththescrews.

2.Adjustthecameratothecorrectdirection.

3. Connect Video Output connector to your DVR.

4.ConnectaDC12VpoweradaptertothePowerInputconnector.

Note

Beforeconnectpower adaptertocamera,pleasemakesure thepower outputvoltageis DC12V(max.

±10%).Ifyoucannotsurethispart,wewillsuggesttouseaDC12VSwitchingpoweradapter.Itcan

providestablypoweroutput.

Specication

Image Pick-up Device

SONY 1/3“ Color CCD

Effective Picture Elements

NTSC:811(H)x508(V)

PAL:795(H)x596(V)

Horizontal Resolution

520horizontalTVlines

Minimum Illumination

0LUXwithbuilt-inIR-LED

S/N Ratio

Morethan48dB

Auto Electronic Shutter

NTSC:1/60s~1/100,000s

PAL:1/50s~1/110,000s

Gain Control

Automatically

White Balance

Automatically(2500K~9500K)

Gamma Characteristic

0.45

Lens Furnished

BoardLens8.0mm/F2.0

View Angle

Horizontal:33degree

Vertical:25degree

Synchronous System

Internal,Negativesync.

Video Output

1Vp-pCompositeVideo/75Ohms

Power Supply

12VDC/100mA(IRon:450mA)

Operating Temp.

-20to60degreeC

Water Resistance

IP-66

IR LED

12Unitsof850nmIRLED

IR Project Distance

50 Meters

Dimensions

95x250mm(φxL)

Weight

925g
