Installation Guide
4
Rechte Seitenhalterung entfernen
Enlevez le support latéral droit
Retire el bracket del lado derecho
Rimuovere la staffa laterale destra
Remove right side bracket Снимите правый боковой кронштейн
우측 사이드 브라켓을 제거합니다
拆除右側支架
拆除右侧支架
右側のブラケットを外して、マザーボードI/Oシールドを取
り付けます
ถอดโครงยึดด้านขวา
ไทย
